3 and 5 axis machining centres with mobile gantry structure
3 and 5 axis machining centres with mobile gantry structure dedicated to the machining of plastic materials and advanced materials and characterized by a rigid and stable frame.
- spindles up to 15 kw and 24.000 rpm ensure high removal capacity and top finishing and accuracy levels under any conditions
- the aluminium worktable is characterized by perfect planarity, ensuring clamping accuracy and advanced nesting machining even with the most severe machining operations on technical details
- gantry structure driven by a highly dynamic dual motor. Solution dedicated to the processing of plastic materials and advanced materials
Advantages
-
HIGH REMOVAL AND PERFECT FINISHING
Removing capacity increased by 7%, faster roughing cycles and absolute compliance with the strictest finishing tolerances.
The fixed table and mobile gantry architecture with dual motorization, consisting of a rigid frame equipped with high-precision front and rear sliding guides, ensures maximum efficiency during heavy removal and incomparable finishing quality in the whole work area. -
FLEXIBILITY AND CLAMPING EFFECTIVENESS
The built-in direct vacuum system and the T-slots allow the optimal clamping of the sheets and the positioning of all types of mechanical clamping equipment. Tolerances are always under control owing to a multi-functional and highly efficient aluminium work table that ensures perfect planarity over time.
-
LIMITLESS MACHINING
The high workpiece throughput dimension and the Z axis travel allow machining workpieces up to 500 mm high. Ideal solution in the production of engineering and prototype parts in plastic materials.
-
THE POWER OF 5 AXIS
PRISMA operating units with 5 interpolating axes equipped with power up to 17Kw 24000 rpm, specifically configured for the processing of plastic materials: this is ideal solution for the production of technical components made of the most performing and demanding resins.
Technical data
| EVOTECH | ||||
| EVOTECH 250 | EVOTECH 400 | EVOTECH 500 | ||
| AXES | ||||
| X-Y-Z axes max. speed (PRO SPEED version) | m/min | 60-60-30 | 90-90-30 | 95-90-30 |
| X-Y-Z axes max. speed (PRO SPACE version) | m/min | 25-60-30 | 25-90-30 | 25-90-30 |
| Z axis work-piece passage (max.) | mm | 250 | 350 | 500 |
| MACHINING HEAD | ||||
| Axes electrospindle motor power (max) | kW | 12 | 17 | 17 |
| 3/4 axes electrospindle motor power | kW | 15 | 15 | - |
| 5 axes electrospindle 5 rotation speed (max.) | rpm | 24000 | 24000 | 24000 |
| 3/4 axes electrospindle rotation speed (max.) | rpm | 24000 | 24000 | - |
| DRILLING UNIT | ||||
| Vertical and horizontal spindles (max.) | n. | 30 | 30 | 26 |
| Rotation speed | rpm | 8000 | 8000 | 8000 |
| TOOL CHANGERS | ||||
| Tool store on machining head | posizioni | 12 | 12 | 12 |
| Rear tool store | posizioni | 32 | 48 | 48 |
| Side tool store | posizioni | 12 | 12 | - |
| Front tool store | posizioni | - | - | 16 |
| INSTALLATION | ||||
| Exhaust air consumption | m³/h | 4430 | 4430 | 4430 |
| Compressed air consumption (min.-max.) | Nl/min | 350-550 | 350-550 | 350-550 |
